Architectural

• Glass Cover: IK10 impact resistance certified according to IEC 62262. Crystal-clear tempered glass with a soda-lime chemical composition, 10-20mm (0.39”) thick. Conforms to RoHS Directive 2011/65/EU and (EU) 2015/863.
• IP Rating: IP68 rated as per IEC 60598-2-23, certified for permanent submersion. Tested for a minimum of 16 hours in an IP chamber with a pressure test of 1.2 bar.
• Installation Depth: Maximum certified installation depth of up to 5m (16’) in saltwater or pool water, per IEC 60598-2-23.
• Material: Aluminium Al606-T6, AL 6082-T5
• Surface Material: CNC-machined from AISI316L stainless steel bars, containing a minimum of 20% recycled material in its composition. Aluminum
• Surface protection: Anodization process applied to aluminum surfaces as per standard xxx. Powder coat/Qualicoat applied as a secondary surface protection and tested through Salt Spray resistance, UV resistance, Corrosion resistance, and durability. Complies to ISO, 9227, ISO 2812, EN 12206-1, ASTM D823
• Environment and material compatibility: Suitable for chlorine and marine environments due to the high corrosion resistance of AISI316L stainless steel.
• Cable: Outer jacket made of EPDM elastomeric rubber, conforming to Class 3 of UL 62, resistant to oil contact up to 60°C, UV exposure, and wet installation. The core consists of an electrolytic flexible bare copper conductor conforming to UL 62 and UL 1581 standards. Supplied with a standard 3m (10’) feed cable.
• Optics: PMMA collimator with 92% transmittance in the 400-900 nm wavelength range. Capable of delivering various beam angles with industry-standard high and mid-power LEDs.
• Cable Gland: External surface made from AISI316L stainless steel, providing extra protection against water intrusion. Inner seal made from Neoprene, offering excellent resistance to environmental factors for effective sealing against moisture, air, and chemicals. Conforms to EN 62444:2013 and EN 60423:2008 standards.
• Silicone: High-performance neutral cure silicone adhesive/sealant designed for strong but flexible bonds. Stable from -40°C (-40°F) to 180°C (356°F). Conforms to RoHS Directive 2011/65/EU and (EU) 2015/863.
• Installation: Designed for press-fit installation, ensuring no visible components after installation, allowing the product to blend seamlessly with the surrounding environment.
• Surface Protection: Passivated per ISO 15730:2023 standard to enhance the natural corrosion resistance of AISI316L stainless steel by removing contaminants that may contribute to corrosion.
• Material Testing: Tested in a salt chamber in accordance with ISO 9227:2017 (NSS test) for 500 hours.

Electrical Details

• LED Lifetime: LED Lifetime TM-21 @ 85°C L90(10K) = 60,500 hours
• Operating Temperature: -20°C (-28°F) to +50°C (122°F), as per IEC 60598-2-23
• LED CRI: >85
• MacAdam Steps: 2-Step MacAdam
• Electrical Insulation Class: III

Sustainability

• Recyclability: 87% recyclable

Controls

• DMX (with compatible LED power supply)
• DALI (with compatible LED power supply)
• 0-10V (with compatible LED power supply)
• Mains (with compatible LED power supply)

Approvals, Standards and Compliance

• EN 60598-2-3 (Outdoor Luminaires)
• IEC 62031 (LED modules for general lighting)
• EN 62471 (Photobiological safety of lamps)
• CE Marking (European Union compliance for safety and environmental requirements)
• RoHS (Restriction of Hazardous Substances)
• IP66/IK10 (Ingress Protection and Impact Resistance)
• ISO 9001 (Quality Management Systems)
• ETL
